Stainless steel gasket plate heat exchanger cooling chiller for beer plant啤酒厂用不锈钢垫片板式热交换器冷却冷水机
The gasket plate heat exchanger consists of a pack of corrugated metal plates with portholes for the passage of the two fluids between which heat transfer will take place. The plate pack is assembled between a fix frame plate and a movable pressure plate and compressed by tightening bolts. The plates are fitted with a gasket which seals the inter plate channel and directs the fluids into alternate channels.The plate corrugations promote fluid turbulence , support the plates against differential pressure. 垫片板式热交换器由一组带舷窗的波纹金属板组成，用于在两种流体之间进行传热。所述板包装配在固定框架板与活动压板之间，通过拧紧螺栓进行压缩。这些板装有密封板间通道的垫片，并将流体引导到备用通道。板的波纹促进流体湍流，支撑板对抗压差。
The number of plates 盘子的数量 is determined by the flow rate, physical properties of the fluids, pressure drop and temperature program.是由流速、流体的物理性质、压降和温度程序决定的。
| Material Sheet of PHL PlatePHL板材料表 | |
| 304 Stainless Steel 304不锈钢 | This is the lowest cost heat transfer plate material.It has a low corrosion resistance and is usually only available in a thickness of 0.4mm.This type of heat transfer plate is typically used on HVAC applications.这是成本最低的传热板材料。它具有较低的耐腐蚀性，通常只有0.4mm的厚度。这种类型的传热板通常用于暖通空调应用。 |
| 316 Stainless Steel 316不锈钢 |
This is the most common heat transfer plate material and is used in many applications.这是最常见的传热板材料，在许多应用中使用。 316 stainless steel has a high conosion resistance and is typically available in thickness from o.4mm up to 0.8mm.316不锈钢具有很高的抗腐蚀性能，通常厚度从0.4 mm到0.8mm不等。 |
| Titanium 钛 | This has a very high resistance to chemical attack including most acids,chlorides,sea water,and chlorine chemicals.Titanium is usually available in thicknesses from 0.5mm up to 0.6mm.这是一个非常高的抗化学攻击，包括大多数酸，氯化物，海水和氯化学品。钛的厚度通常从0.5毫米到0.6毫米不等。 |
| Material Sheet Of PHE FramePHE框架材料表 | |
| Frame 框架 | Stainless Steel Covered 不锈钢外壳 |
| Carton Steel 纸箱钢 |
